Pounding Machines

Operating Principle of Pounding Machine

A pounding machine consists of a set of heavy steel pounds, loosely held vertically in a frame, in which the pounds can slide up and down. They are lifted by cams on a horizontal rotating shaft. On Indian Machine Mart pounding machine, the cam is arranged to lift the pounds from the side, so that it causes the pound to rotate. As the cam moves from under the pounds, the pounds falls onto the material below, crushing the rock, spices, roots etc and the lifting process is repeated at the next pass of the cam. Indian Machine Mart specially designed liver to lock/unlock the pounding process. Sieving can be done while hammering is locked/stopped.

Construction of Pounding Machine

Pounding Machine ( Kandap Machine) Made from heavy duty iron fabricated Structure. Having 50 mm diameter X 1200 mm Length Hammers which is leafs by Steel Cam. Pound plate from Cast iron and covering Chamber from Sheet. Mild Steel Fabricated automatic stirrer in the chamber to shift the materials while hammering. A special Deigned liver to lock and unlock the hammering process sieving can be done while hammering is locked / stopped.

Typical Application of Pounding Machine

The IMM Pounding Machine can be used for a wide range of application e.g. Herbs & Spices like read chilies, Black pepper , White pepper, Cinnamon, Cardamom, Coriander, Red pepper, Oregano, Basil, Thyme, dill seed, shell corn, Gingko, Ginseng, Cava, Black cohosh, Ginger root, Yucca root, Cassava root,et cetera

Outstanding Features of Pounding Machine

• Unique and Reliable Design
• The pounding series Machines are highly effective as well as non stop continuous pulverizing process.
• Compact size
• Dust free operation
• Ideal for dry crushing
• Increased production leading to faster return on the investments
• Rail For Motor Adjustment
• Machine & Motor Pulley
• V Belt for Motor & Fly Wheel
• Ideal Pulley
• Low Temperature Rise for Heat Sensitive Materials

Standard accessories of pounding machine

• Motor & machine pulley & v belts
• Vibrating stirrer for moving ground materials
• Ground material vibrating screening system with lock & unlock provision

Extra accessories of pounding machine

• Suitable totally enclosed fan cooled three phase or single phase sq. Cage motor {electricity (special power can be accommodated): 220/380/415 volts, 50/60 Hz, 1/3 phase }
• Suitable miniature circuit breaker with 3 meter cable & 3 pin top for single phase electric motors or starters, main switch, ampere meter, capacitor for single phase electric motor.
• Foundation bolts
• All contacting parts stainless steel 304 / 316 can be accommodated
• Different mesh screen for grading ground materials
