Power Storage Testing System, Ev Battery Testing System

IGBT EVHEVPHEV battery test equipment.
***EVTS-500V300A***
EVTS-500V300A is mainly developed for big battery pack. As a new-generation power battery tester with high voltage
and current, having power components and control methods different from the traditional ones, EVTS-500V300A is the ideal solution to power batteries and power-storing batteries.
Popular modelsSize：
*EVTS-500V100A: 1350*733*1800(mm)
*EVTS-500V300A: 1350*733*1800
*EVTS-600V500A: 1350*733*1800
*EVTS-600V700A: 2000*1000*2120
*EVTS-700V100A: 1350*733*1800
*EVTS-750V300A: 1500*900*1800
*EVTS-800V600A: 2000*1000*2120
*EVTS-800V1000A: 2300*1400*2300
Specifications:
*Input power: AC 380V ± 10% 50HZ60HZ
*Output range(Customizable): Voltage 100-800V
*Resolution: AD: 16bit; DA: 12bit
*Control accuracy: ±0.1% of FS
*Measuring accuracy: ±0.1% of FS
*Discharging energy: can be returned back to the electricity grid
*Rise Time: ≤1s (10%-90%）
*Data recording rate: 1HZ，10HZ（customizable） (Max), 1 or 10data point per second,Support.(ΔTimeΔUΔl) as recording conditions
*Operating modes: Charge: Constant Current, Constant Voltage, constant current & constant voltage
Discharge: Constant Current, Constant Power
Aux channel test(For single cells’voltage and temperature):
*temperature range: thermal resistance: -10℃～85℃
thermocouple: -80℃～200℃
*temperature accuracy：±2℃
*voltage range：10mV-5V
*voltage accuracy：±0.1% of FS
Application:
*Can test: voltage,current,capacity,energy output capability;
*Test the battery parameters: cycle life, over-charging, over-discharging;
*Grading function: test and estimate the consistency of single cells in each battery pack;
*CAN bus communication port: support communication with BMUBMS;
*Set rate test: set charge and discharge rate.
