Pq-400 Double Spring Nozzle Tester

We are offering pq-400 double spring nozzle tester.
Functions:
test and calibrate normal injector and diesel double springs injectors.
1. Equipment with a manometric gauge for internal pressure regulation
2. Digital display permits to calibrate the injector opening pressure
3. One shot and continuous spraying test
opeartion:
main button:
a: internal pressure meter
b: air supply meter
c: air supply throttle
if the throttle whirls in clockwise, quantity of air input will be less, and oil input is less as well. Inverse, the input oil will increase.
D: governor valve
if the governor valve circumgyrate to the bottom, rate of oil pressure and air pressure is 100:1. For example, when air pressure 7kg, the oil pressure will be 700kg.
e: air switch valve
the air valve is opened by pulling, and closed by pushing.
