| Features :- | |||||||||||
| Output Voltage Adjustable from 0 to Specified Voltage. | |||||||||||
| Current Limit Adjustable from 5% to 110% of Specified Load Current. | |||||||||||
| Two Completely Isolated Outputs can be configured in Series or Parallel to Enhance Voltage or Current Output Capacity Respectively. | |||||||||||
| Regulation : Voltage (CV) : Load & Line        : ± 0.01 % max.                   : Current (CC) : Load & Line      : ± 0.05% max. | |||||||||||
| Ripple : CV : 1 mV (r. m. s.) Max., : CC: 0.03% Amp. (r. m. s.) Max., | |||||||||||
| Protected Against Overload & Short Circuit by Means of Automatic Crossover Characteristics. | |||||||||||
| Externally Programmable Output Voltage. | |||||||||||
| Remote Sensing for Distantly Situated Loads. | |||||||||||
| Continuous Metering of Output Voltage & Current. | |||||||||||
| Input Voltage: 230V AC ±10%, 50Hz, Single Phase. | |||||||||||
Operating Temperature Range: 0 to 55Â 0Â C.
| |||||||||||
| MODEL | DESCRIPTION | MODEL | DESCRIPTION |
| SVP 032001 | 0 - 32V / 1A | SVP 064010 | 0- 64V / 10A |
| SVP 032002 | 0 - 32V / 2A | SVP 064015 | 0-64V / 15A |
| SVP 032003 | 0 - 32V / 3A | SVP 064020 | 0- 64V / 20A |
| SVP 032005 | 0 - 32V / 5A | SVP 064030 | 0- 64V / 30A |
| SVP 032010 | 0 - 32V / 10A | SVP 100001 | 0- 100V / 1A |
| SVP 032015 | 0 - 32V / 15A | SVP 100002 | 0- 100V / 2A |
| SVP 032020 | 0 - 32V / 20A | SVP 100003 | 0- 100V / 3A |
| SVP 032030 | 0 - 32V / 30A | SVP 100005 | 0- 100V / 5A |
| SVP 064001 | 0 - 64V / 1A | SVP 100010 | 0- 100V / 10A |
| SVP 064002 | 0 - 64V / 2A | SVP 100015 | 0- 100V / 15A |
| SVP 064003 | 0 - 64V / 3A | SVP 100020 | 0- 100V / 20A |
| SVP 064005 | 0 - 64V / 5A | SVP 100030 | 0- 100V / 30A |
| SVP 032100 | 0 - 32V DC / 100A | |
