Precision Etching Machine

We are offering Precision Etching Machine.
main parameters:
model number: jm650
power 12kw/380v/50hz
etching area 650*lmm
etched type double chamber and swing
tolerance: 0.02mm
maching thickness 0.05~2mm
working temperature 0~65℃
machine size 3500*1650*1550mm
weight 850kg
features:
1.the body is made of high quality pvc/pp materials from germany.
2.high transparency toughened glass design, it's convenient to observe internal spraying and transmission.
3.adopted special oscillatory device and high pressure system,so the praying is more uniform and it could reduce the etching pool effectively.
4.the tolerance can be control bellow 0.03mm, it can satisfy your high precision requirements.
5.the speed can be adjusted, and the best temperature could be ensure by automatic heating and cooling device.
6.special design for etching pump and the shaft uses titanium materials with good corrosion resistance
7.simple operation and easy to maintain and it's very suitable for mass production.
8.can be customized according to customer's detail requirements.
