Industry where use
| Description | UC-HP-3030 | UC-HP-4040 |
|---|---|---|
| Working Area (X) x (Y) x (Z) in mm | 300 (X) x 300 (Y) x150 (Z) | 400 (X) x 400 (Y) x 150(Z) |
| Table Size-Clamping Area | 350 (X) x 350 (Y) | 500 (X) x 400 (Y) |
| T Slot Size | 14 mm. | |
| T Slot Centre Distance | 75 mm. | 80 mm. |
| Rapid Feed Rate | 15000 mm/min | |
| Cutting Feed Rate | 10000 mm/min | |
| Spindle Speed | 3000 – 24000 | |
| Spindle Power | 2.2 KW | |
| Spindle type | HIGH PRECISION HF SPINDLE WATER COOLED | |
| Collet Nose | ER-20 | |
| Maximum Tool Diameter | 12.5 mm. | |
| Guide System | HIWIN Make Linear Motion Guide with PRELOAD | |
| Drive System | PRELOADED GROUNDED BALL SCREW | |
| Ball Screw Class & Diameter | HIWIN MAKE C3 CLASS / 25 mm. | |
| Motor & Drive | Absolute SERVO Drive | |
| Spindle Drive | Sensorless Vector Control | |
| Ball Screw Diameter | 25mm | |
| Standalone Controller | DELTA / SIEMENS / FANUC | |
| USB Connectivity | Yes | |
| LAN Connectivity | Yes | |
| Job Size Measurement | Yes | |
| Manual Pulse Generator (MPG) | Yes | |
| Feed Over-ride | Yes | |
| Synchronized Interpolation | Yes | |
| Work Co-ordinate | G54 to G59 | |
| Full Closed Loop Control System | Yes | |
| Machine Self Zero | Yes | |
| User Work Zero (G54) | Yes | |
| Auto Spindle On/Off | Yes | |
| Auto Coolant On/Off | Yes | |
| Tool Break Point Resume | Yes | |
| Power Resume Function | Yes | |
| Positional Accuracy | Err:510 | |
| Repeatability | Err:510 | |
| NC File Format | Standard ISO G-Code | |
| Table to spindle nose when down | 25 mm | |
| Machine Weight (Approx.) | 850 Kg. | 950 kg. |
| Operating Temperature | 5 to 35 Degrees | |
