| Number of Analog Input Channels | 16 |
| Gain/Trim Range | Line: -20 dB to +20 dB (Balanced) Mic/Line: -16 dB to +67 dB |
| Gate Parameters | Threshold: -84 to 0 dB Attack: .2 ms to 2.5 ms Release: 70 ms |
| Compressor Parameters | Threshold: -56 to 0 dB Ratio: 1:1 to 14:1 Attack: .2 ms to 180 ms Release: 150 ms to 1.0 sec Knee: Soft / Hard |
| EQ Parameters | HF Shelf: ±15 dB at 1.4 kHz to 18 kHz (Shelf or Bell Selectable) MF Notch/Peak: ±15 dB at 260 Hz to 3.5 kHz LF Shelf: ±15 dB at 36 Hz to 465 Hz (Shelf or Bell Selectable) |
| Sample Rates | 44.1 / 48 kHz |
| Bit Depth | AD/DA Conversion: 24-Bit |
| DSP | 32-Bit Floating Point |
| Converter Dynamic Range | A/D: 118 dBA at 48 kHz D/A: 118 dBA at 48 kHz |
| Jitter | < 20 ps RMS |
| Jitter Attenuation | > 60 dB |
| dBFS Reference Level | +18 dBu = 0 dBFS |
| Frequency Response | Direct Output: 20 Hz to 20 kHz 0/-0.5 dBu (2901653073) Main Output: 20 Hz to 20 kHz ±0.5 dBu (2901653073) Line Input to Direct Output: 10 Hz to 40 kHz -0.5 dBu (2901653073) Line Input to Main Output: 20 Hz to 20 kHz -0.5 dBu (2901653073) |
| Max Input Level | Line Input: +22 dBu (Unbalanced) Line Input: +22 dBu at Unity Gain (Balanced) Mic Input: +16 dBu |
| Output Level | Aux Output: +18 dBu Main Output: +24 dBu Monitor Output: +18 dBu |
| I/O Impedance | Line Input: 10 Kilohms Main Output: 100 Ohms Aux Output: 100 Ohms Monitor Output: 100 Ohms Mic Input: 1 Kilohms |
| Crosstalk | Input to Output: -90 dBu Adjacent Channels: -87 dBu |
| CMRR | 65 dB at Unity Gain |
| EIN | 125 dB 130 dB (2901653035) |
| SNR | Line Input to Direct Output: -105 dBA at Unity Gain (+4 dBu Reference) Line Input to Main Output: -95 dBA at Unity Gain (+4 dBu Reference) Mic/Line Input to Direct Output: -102 dBA at Unity Gain (+4 dBu Reference) Mic/Line Input to Main Output: -95 dBA at Unity Gain (+4 dBu Reference) |
| THD | Line Input to Direct Output: Line Input to Main Output: Mic/Line Input to Direct Output: Mic/Line Input to Main Output: 0.005% at Unity Gain (+4 dBu, 2901653246) |
| Analog Inputs | 8 x 1/4" TRS Balanced Input 2 x Stereo RCA Unbalanced Input 12 x Balanced Mic Input 8 x 1/4" TRS Balanced Line Input (4 Stereo Pairs) |
| Analog Outputs | 2 x Balanced Main Output (1 Stereo Pair) 2 x 1/4" TRS Balanced Monitor Output (1 Stereo Pair) |
| Phantom Power | +48 V |
| USB | 1 x USB Type-B (USB 2.0, Host Connection) |
| OS Compatibility | macOS 10.8.5 or Later Windows 7 Windows 8.1 Windows 10 iOS 9.3 or Later Android 5.0 or Later *As of July, 2019: Check with manufacturer for the most up-to-date compatibility |
| Processor Requirement | Intel Core 2 Duo |
| RAM Requirements | 4 GB, 8 GB Recommended |
| Storage Requirements | 30 GB |
| Mobile Device Compatibility | iPad Android Smartphone Android Tablet |
| Minimum Display Resolution | 1366 x 768 |
| Internet Connection | Yes |
| Required Hardware | USB 2.0 Port |
