Contact SupplierWe ensure our entire range of products is per domestic as well as transnational quality standards, optimum grade and worth the price paid by purchaser. The organization is supported by systematized packaging system which assists us in meeting the specific packaging requirements of the clients with ease. Also, we ensure zero damage to the products.
Price : $60600-65900 per set
Advantages
Applications : It’s used in construction building site, such as Multi commercial housing, High rise building, Skyscraper, and Workshop Material handling etc.
| Application | Buildings And Projects |
|---|---|
| Max. Load | 6t |
| Tip. Load | 1.0t |
| Mast section | 1.6*1.6*2.5m (Block Type) |
| Type | Fixed With Tower Head |
| Jib Length | 55m |
| Power supply | 380V/50Hz Or According To Client's Requirements |
| Main Chord | 135*10mm (square Tube) |
| Rated lifting moment (kN.m) | 630 | |||||
| Lifting height (m) | Rope fall | Free-standing stationary crane | Anchored crane | |||
| α2 | 40 | 150 | ||||
| α4 | 40 | 150 | ||||
| Working radius (m) | Max. working radius | 55 | ||||
| Min. working radius | 3 | |||||
| Max. lifting capacity (t) | 5 | |||||
| Hoisting mechanism | Rope fall | α2 | α4 | |||
| Speed (m/min) | 80/40/8.5 | 40/20/4.25 | ||||
| Lifting weight (t) | 1 | 2.5 | 2.5 | 5 | ||
| Power (kW) | 24/24/5.5 | |||||
| Tolleying mechanism | Speed (m/min) | 0.6 | ||||
| Power (kW) | 3.7 | |||||
| Slewing mechanism | Speed (r/min) | 0.4 | ||||
| Power (kW) | 4 | |||||
