| Pipe Nominal Bore / Process Flange Size | Min. Lenth | Total Lenth(L) | PTFE Liner Thicknesh | Pipe Schedule | Vessel Flange | NB Min Inlet Nozzle ID | ||
|---|---|---|---|---|---|---|---|---|
| Inches | MM | Min. MM | Max. MM | MM | MM | Min. MM | Max. MM | MM |
| 1" | 25 | 60 | 6000 | 2.5 | 40 | 1 1/2" | 24" | 45 |
| 1 1/2" | 40 | 70 | 6000 | 2.8 | 40 | 3" | 24" | 60 |
| 2" | 50 | 75 | 6000 | 3 | 40 | 3" | 24" | 73 |
| 3" | 80 | 85 | 6000 | 3 | 40 | 4" | 24" | 101 |
| 4" | 100 | 90 | 6000 | 4.5 | 40 | 6" | 24" | 130 |
