PU Cold Room Sandwich Panels With Foam Polyurethane

Product Brief :
Number base plate THK and applicable temperature range:
50mm high temperature (5°C or above)
75mm medium temperature (-5°C or above)
100mm low temperature (-30°C or above)
150-200mm ultra low temperature (-45°C or above)
Product Type : XPANEL
Panel details:
Panel width: 960 and 1000mm
Panel length: 12,000mm
Steel thickness: 0.4/0.5/0.6/0.8mm
Regular steel sheet color code: RAL 9002 (grey white)
PU density: 40 ± 2kg/m3
Heat transfer coefficient: 0.024W/m * k
Bending strength: 331MPa
Fire rating: B2
Surface of panels: can choose various type of surface materials
Standards: JB and T6527 to 2006
Cold storage panel option (by various materials)
Stainless steel
Painted galvanized steel
Galvanized steel
50mm high temperature (5°C or above)
75mm medium temperature (-5°C or above)
100mm low temperature (-30°C or above)
150-200mm ultra low temperature (-45°C or above）
Walk in freezer size and temperature can be made according to customer's requirements
polyurethane panels are used for enclosing structures, which has good heat insulation and
high intensity core is high rigid polyurethane and external is color steel or stainless
steel can reduce heat transmission caused by different temperature between internal and
external and so maximum efficiency of freezing and refrigerating systems
Scientifically design and convenient use and it has become material for lower construction cost
Applications
Using 100% polyurethane insulation panel, density about 40-45kg/m3 and with gasket with flame
retardant
Food (meat, vegetable, fruit, dairy and drink), medicine, chemical and electronics
Materials: polyurethane and metal sheet metal sheet: it is can be with painted steel sheet
and stainless steel sheet for choice
Electric heating wire around door frame to void icing
Safe door knob inside
Positive plastic seal fixed to door to avoid cooling air losses
Can do customized dimension according
