Public Address System For Fire

Clients can avail from us the latest technology Public Address System. Designed using the recent methodology, the Public Address System is quite efficient. Public Address System can be availed from us in different configurations. We are a renowned Public Address System Supplier in Maharashtra (India). Our office Paging/Music systems for announcement are high in demand amongst the buyers.

Evaclitepkg
8 Zone, Voice Alarm controller with built-in USB,
MP3, AM/FM player (with 8 zone paging station)
SPECIFICATIONS EVACLITEPKG
Line Input
Microphone Input 600 ohms 10mV, unbalanced
Remote Paging Microphone
with zone selection
Signal Input frequency: 100Hz~10KHz
Signal Input Sensitivity: 5V RMS
Communication: RS485 mode,
Transmission distance: 1000m
10K ohms 775mV, unbalanced
Line Output 775mV
Frequency Response 20Hz~20KHz
Total Harmonic Distortion(THD) <0.01% at 1KHz
Signal Noise Ratio(S/R) >70 dB
Alarm Activation Input 0V Short Circuit Signal
Timing Activation Input 0V Short Circuit Signal
Alarm Activation Output 0V Short Circuit Signal
Power Output Capability 5A
Constant Voltage Input 100V
Subarea Channel Power ≤500W (single channel,Total power ≤1000W)
Frequency Range
FM : 87.5MHz ~ 108MHz
AM : 531KHz ~ 1710KHz
Power Supply Voltage AC 220V ± 10% 50/50Hz
Rated Power 20W
Packing Dimension (W×H×D) 540×577×250mm
Gross Weight 10.6Kg
• 8 Zone Paging system with pre-recorded
messages for voice evacuation
• Adopts LCD screen for easy operation
• Simple integration with Fire Alarm Panels to
activate EVAC/ALERT pre-recorded messages.
• Supports timing broadcast, manual broadcast,
external timing activation broadcast and alarm
activation broadcast.
• Provides up to 4 sets of scheduling options
• Built-in MP3 (USB) and FM/AM functions
• Built-in loudspeaker for performing broadcast
monitoring, with special monitoring volume control
• 1 line input
• 1 microphone input, provides mix and emergency
paging output modes.
• Provides 8 broadcast zone output function, the
peak power of each zone is 400W, and the total
power of the all 8 zones is 1000W
• 1 alarm activation input and 1 timing activation
input
• 1 alarm activation output
