Punching machine

We are offering punching machine
product name: separation of hydraulic punching machine
function: bus bar hole puncher,stainless steel punch,punching
separate hydraulic punching machine for l, h flat steel, copper and aluminum row punching machine.
Block the bottom of the design of flat, smooth easy to shake down.
Oil return hole type, mold easily damaged by high carbon tungsten alloy.
Ch-60, ch-70 split hydraulic punching machine, designed to angle iron, flat iron, copper and other metal sheet punch, especially for electricity, construction and other industries operating in the field site, with the pump cp-700, cp-700-2a, cfp-800, dyb-63a.
Syd-35 metal punch machines, the following is a 1.5mm stainless steel in a hole on the advanced hydraulic hand tools, stamping equipment can play the hole can not achieve the role of the simple, labor-saving, speed, processing surface smooth and clean, free space, position limits, the use of safe and reliable.
Type / thickness (mm) / tonnage (tons) / throat depth (mm) / weight (kg) / standard punching die / remarks
ch-60/10/31/95/13.5 3 / 8 "(ø10.5), 1 / 2" (ø13.8), 5 / 8 "(ø17), 3 / 4" (ø20.5)
ch-70/12/35/110/28 3 / 8 "(ø10.5), 1 / 2" (ø13.8), 5 / 8 "(ø17), 3 / 4" (ø20.5) / factory unworthy of the pump, can be optional
syd-35/1.5/12/100/12.5 ø26, ø35 / factory is equipped with cp-180
