PVC Four Pipe Extrusion Machine, Brand Name : TPM

Pvc four pipe extrusion machine
advantanges:
1. Gf series plastic pipe production line is mainly used in manufacture of the plastic pvc pipes with diameters of 16-32mm, it can produce 4 pcs pvc pipes at same time, which greatly improved production efficiency.
2. This pvc four pipe making machine is composed of conical double-screw extruder, vacuum calibration table, haul-off, cutter, stacker etc.
3. The extruder and the haul-off adopt the quality ac frequency conversion control device.
4. The vacuum pump and motor adopt the famous brand.
5. It may choose the saw blade cutting type or the planet cutting production efficiency.
6. Our company may equipped the special device for the manufacture of the inner wall spiral coil and core layer blister according to the client’s requirement.
Main parameters:
no device name qty
1 sjz-65 conical twin screw extruder 1set
2 mould(including:mouth piece,core mandril,sizing sleeve,diameter16.20.25.32mm) 1set
3 4 in 1 pvc pipe vacuum cool tank 1set
4 4 in 1 pvc pipe hauling-cutting chip-free combination 1set
5 4 in 1 pvc automatic pipe rank 1set
