| Nominal Bore/Size |
Type | Wall Thickness | Safe allowable Hydrostatic Pressure Kgf/cm2 |
Safe Delivery Head M |
Package | |||
|---|---|---|---|---|---|---|---|---|
| END | BARREL | |||||||
| Min | Max | Min | Max | |||||
| 25MM (1″) | V4 | 4.7 | 4.9 | 2 | 2.3 | 15 | 150 | 3 mtr |
| 25MM (1″) | CRYSTAL | 5 | 5.3 | 2.5 | 2.8 | 21 | 210 | 3 mtr |
| 25MM (1″) | STANDARD | 4.95 | 5.3 | 4 | 4.5 | 30 | 300 | 3 mtr |
| 32MM (1 1/4″) | V4 | 4.2 | 4.5 | 2.4 | 2.7 | 15 | 150 | 3 mtr |
| 32MM (1 1/4″) | CRYSTAL | 4.8 | 5.1 | 2.8 | 3.1 | 21 | 210 | 3 mtr |
| 32MM (1 1/4″) | STANDARD | 6.3 | 6.5 | 4.1 | 4.3 | 25 | 250 | 3 mtr |
| 32MM (1 1/4″) | HEAVY | 6.4 | 6.9 | 5.2 | 5.8 | 35 | 350 | 3 mtr |
| 40MM (1 1/2″) | V4 | 4.5 | 4.8 | 2.7 | 3 | 15 | 150 | 3 mtr |
| 40MM (1 1/2″) | CRYSTAL | 5.3 | 5.6 | 3.5 | 3.8 | 21 | 210 | 3 mtr |
| 40MM (1 1/2″) | STANDARD | 6.6 | 6.8 | 4.1 | 4.4 | 26 | 260 | 3 mtr |
| 40MM (1 1/2″) | HEAVY | 8.4 | 8.6 | 5.9 | 6.1 | 35 | 350 | 3 mtr |
| 50MM (2″) | MEDIUM | 5.1 | 5.4 | 2.6 | 2.9 | 13 | 130 | 3 mtr |
| 50MM (2″) | STANDARD | 6.4 | 6.8 | 3.9 | 4.3 | 20 | 200 | 3 mtr |
| 50MM (2″) | HEAVY | 7.9 | 8.4 | 5.3 | 5.7 | 27 | 270 | 3 mtr |
| 65MM (2 1/2″) | MEDIUM | 5.1 | 5.4 | 2.6 | 2.9 | 10 | 100 | 3 mtr |
| 65MM (2 1/2″) | STANDARD | 6.5 | 6.9 | 4 | 4.4 | 16 | 160 | 3 mtr |
| 65MM (2 1/2″) | HEAVY | 8.5 | 9.3 | 6.3 | 6.8 | 26 | 260 | 3 mtr |
| 80MM (3″) | MEDIUM | 5.7 | 6.1 | 3.2 | 3.5 | 11 | 110 | 3 mtr |
| 80MM (3″) | STANDARD | 7.5 | 7.8 | 5 | 5.5 | 17 | 170 | 3 mtr |
| 80MM (3″) | HEAVY | 9.8 | 10.3 | 7.3 | 7.8 | 26 | 260 | 3 mtr |
| 100MM (4″) | MEDIUM | 6.3 | 6.6 | 3.8 | 4.3 | 10 | 100 | 3 mtr |
| 100MM (4″) | STANDARD | 8.2 | 8.5 | 5.7 | 6.2 | 15 | 150 | 3 mtr |
| 100MM (4″) | HEAVY | 11.9 | 12.3 | 9.4 | 10 | 26 | 260 | 3 mtr |
| Column Pipe Type | Pipe Size | Pipe size, mm | Submersible Pumps size | |||||
|---|---|---|---|---|---|---|---|---|
| Crystal | 1″, 1¼”, 1 ½” | 25, 30, and 40 | Upto 100mm sub. Pump | |||||
| Medium | 2″ 2½”, & 3″ | 50, 65 and 80 | Upto 150mm sub. Pump | |||||
| 3″, 4″ | 80, 100 | Upto 200mm sub. Pump | ||||||
| Standard | 1″, 1¼”, 1 ½” | 25, 30, and 40 | Upto 100mm sub. Pump | |||||
| 1¼”, 1 ½”, 2″ & 2½” | 30, 40, 50, and 65 | Upto 150mm sub. Pump | ||||||
| 3″, 4″ | 80, 100 | Upto 200mm sub. Pump | ||||||
| Heavy | 1¼”, 1 ½”, 2″, 2½”, & 3″ | 30, 40, 50, 65, and 80 | Upto 150mm sub. Pump | |||||
