Model Apply belt width(mm) Rated height(mm) Magnetic field at rated height (mT) Attracting capacity
(kg) Main dimensions weight(gk)
Cores type
A B C D E
RCDK-50A 500 120 50 0.1-25 528 76 117 400 280 76 Rare Earth Magnets
RCDK-65A 650 150 628 97 130 500 280 97
RCDK-800A 800 200 828 248 160 700 420 248
RCDK-100A 1000 230 1028 390 160 850 550 390
RCDK-1200A 1200 250 1228 540 160 900 550 540
RCDK-50B 500 100 45 598 165 209 450 400 165 Ferrite
RCDK-65B 650 120 728 257 191 600 500 257
RCDK-80B 800 180 828 420 219 700 550 420
RCDK-100B 1000 200 1028 496 219 850 550 496
RCDK-120B 1200 220 1228 600 219 900 550 600
