Contact Supplier| IS Code | IS 15683 | IS 2878 |
|---|---|---|
| Type | sTORED Pressure | sTORED Pressure |
| Filling Ratio | 0.667 | 0.667 |
| Test Pressure | 250kgf/cm2 | 250kgf/cm2 |
| Operating Pressure | -20oC TO +55 oC | - |
| Min effective Discharge | 95.00% | 95.00% |
| Type OF extinguisher media | CO2 GAS | CO2 GAS |
| Capacity | 2kg | 3kg | 4.5kg | 6.5kg | 9kg | 22.5 Kg |
|---|---|---|---|---|---|---|
| Fire Rating | 8b | 13b | 21b | - | ||
| Discharge Tine | Min. 8 S | Min. 11 S | Min. 13 S | - | ||
| Dicharge Range (Min.) | 1 Mtr | 2 Mtr | 2 Mtr | 2 Mtr | ||
| Operating Valve (IS :3224) | Wheel/Squeeze Grip Type | |||||
