Contact SupplierWe are offering reel wrapper,
wmr203 reel wrapper is a machine designed for packing rolls of paper, non-woven, film and similar products made in rolls. It is the ideal wrapper for reel type products to achieve dust and moisture proof and enhanced packing effects for transport and storage.
main specification:
wrapping size: l(500-1500)mm;w(500- 1600)mm
packing speed: 20-40 pcshour
loading weight: 2000kg
turntable speed: 0-15rpm, speed variable, turntable soft start & soft stop
turntable height: 460mm (ejection type:530mm)
carriage speed: 3mmin
control: plc (mitsubishi panasonic)
class: automatic
power: 3ph 380vac, 5060hz, 20a, 3.4kw, others as an option
machine dimension: 2950×1800×2582mm
machine weight: 1100kg
features:
*powered pre-stretch film carriage, radio 250%.
*automatic wrapping according to pre-set parameter.
*auto height detection, turntable home position.
*roller speed adjustable.
*dual limit switch on top & bottom for better protection.
