Description :the set up demonstrates the students about the basic principal of a refrigeration cycle. The test rig is designed for the study of thermodynamics of vapor compression refrigeration cycle by way of demonstration and experimentation. It has a facility to measure various parameters for experimentation.
Experimentation:
to calculate refrigerant capacity.
to study the vapour compression refrigerator cycle.
to calculate co-efficient of performance and draw p-h diagram.
Utilities required :
electric supply 5a-220 v ac
water supply and drainage
floor area : 1.5 m x 1m
technical details :
compressor : hermitically sealed compressor.
capacity 13 ton, kirloskar make.
agitator : compatible capacity.
condenser : air cooled compatible to 13 ton compressor
condenser cooling fan : compatible capacity with permanent lubricated motor.
evaporator : made of stainless steel, insulated with ceramic woolp.u.f.
rotameter : range 6 to 60 lph
expansion device : capillary tube, compatible capacity.
pressure gauges : 2 nos. Safety control : overload and over current protectors for
compressor and time delay circuit. Temperature sensor : rtd pt-100 type.
control panel comprises of :
digital voltmeter : 0-300 v
