Ridge Capping Forming Machine

A renowned manufacturer, exporter and supplier of roll forming machines in Yingkou, Liaoning, Sanxing manufactures Ridge Capping Forming Machine and has been in the market for over a decade while continuously improving on its quality. This roll forming machine is designed to manufacture high quality steel ridge capping for steel stepped tile.
More about Ridge Capping Forming Machine : The machine comes with reel type uncoiler, rear-cuter, crimping device, optional pre-cutter, and a safety manual.

Components of Ridge Capping Forming Machine :

• Cold Roll Forming Machine (1 set)
• Reel Type Uncoiler (1 set)
• Rear-Cutter (1 set)
• Crimping device (1 set)
• Pre-Cutter (Optional)
• Safety Guide (Optional) â€“ emergency stop wire, PVC cover etc

Features of Ridge Capping Forming Machine :

• Professional design and manufacture of steel ridge capping.
• Programmable Logic Controller (PLC) - Automatically manufactures high quality products continuously.
• Man Machine Interface (MMI) - Directly input the data by the touch screen.
• Hydraulic drive, shear and crimping device.
• Design the machine on customers' requirements.
• Hydraulic system with high running speed saves time and cost.
• One year warranty.

Technical Specification of Ridge Capping Forming Machine :

• Thickness of Forming Sheet : 0.4 ~ 0.6 mm (Pre-painted steel).
• Forming Speed : 4 ~ 6 M/min.
• Roll Shaft Diameter : 60 mm. 4 Number of Station: 8 ~ 10 sets.
• Main Motor : 7.5 HP.
• Complete with mandrel type uncoiler and hydraulic cutting device.
• Complete with one set of crimping mold.
• This machine is controlled by computer system with touch screen.
