Ring Forming Machine

We are offering ring making machine.
Specification
model: r-6-300 e-series
input voltage: 380v(3-phase) or custom
power frequency: 5060hz
instant power during welding: 15kva(for 4mm wire)
instant power during forming: 2kva
wire thickness: 2.8-5mm
max ring diameter: 300mm
min ring diameter: 70mm
ring diameter tolerance: 0.16mm
cooling: natural cooling
air flow required: 250lmin
air pressure: 0.6-0.8mpa
throughput: about 1560pcshr(for ring diameter 150mm)
weight: 1000kg
features
r-6-300 e-series is not equipped with digital regulation of ring sizes, the ranges of ring thickness and ring size are also less than r-6-300.
1. High precision: intelligent "s" shape speed curve, the encoder and the motor form a closed-loop wire feeding control system, secure a diameter tolerance less than 0.16mm, eventually solve the ring precision issues inherent in the traditional mechanical or hydraulic ring making machines.
2.high stability: wire feeding unit is driven by two motors directly without gears, belts or other transmission parts which would get less precise due to wear-out.
3.easy operation: ring size is adjusted by turning the wheels, much easier than traditional mechanical or hydraulic machines.
4. Automatic ring welding: worker attendance is not required during machine operation.
5. Compatible welding: capable of welding low, medium and high carbon steel, spring steel, galvanized steel.
