RM 500 Reversible Mixer Machine, Certification : ISO 9001:2008 Certified

₹ 3.45 Lakh - ₹ 5.10 Lakh / piece

Chassis MaterialM.S
Automatic GradeSemi Automatic
Driven TypeMechanical, Hydraulic
CertificationISO 9001:2008 Certified
Supply TypeManufacturer, Exporter, Supplier, Retailer, Trader
Preferred Buyer Location All over the world

Company Information

4.7/5

Member Since 8 Years
Nature of Business Manufacturer
GST No. 24AIIPT7106Q1ZN

Ask for more detail from the seller

Report incorrect details

Product Details
Company Details

Automatic GradeSemi Automatic
Power3-6kw
ApplicationCONCRATE MIXING
CertificationISO 9001:2008 Certified
Charging Capacity10
Outline Dimension2Mx2Mx2M
Drum Capacity500
Number Of FlowerReversible Mixer Machine,rm500 di
Availability370
Total Carbohydrate1year
After-Sales Service ProvidedYES
Country of OriginIndia
Mixer Typenormal
Brand NameHARSIDDH,kirloskar
Driven TypeMechanical, Hydraulic
Chassis MaterialM.S
ConditionNew
Materialm.s

Particulars Specifications

Hopper capacity 500 liters

Batch capacity 350 liters

Machine output /hour 08 CUM

Prime mover Diesel engine

Jack leveling 4 pin type jack

Water tank capacity 130 liters

Water pump Pulley driven self priming water pump

Water discharge system Solenoid valve operated auto water feeding system

( at each batch operator needs to press push button to

discharge)

Weighing system Digital Load cell based weighing

Hydraulic system for hopper Hydraulic cylinder operated

Gear ring and roller Accurately machined gear ring and rollers for the better

durability

Hydraulic system for mixer Hyd. Motor

Tyres 4 no of pneumatic tyres make

Mixing and discharge of concrete Forward rotation of mixer mixes and reverse rotation

for the discharge of concrete

Three bin system Yes

Mixing drum rpm 16 -18 rpm

Towing speed and system 22 km /per hour

Battery Exide make standard battery

Control panel Microprocessor based control panel

(scada system control panel ) extra ret in your location

Tool box Yes

Diesel engine 10 hp standard diesel engine with self start system and

alternator

( HTC ENGINE/kirloskar engine )

Additional Information

Payment Terms D/P
Port of Dispatch3
Packaging DetailsParticulars Specifications Hopper capacity 500 liters Batch capacity 350 liters Machine output /hour 08 CUM Prime mover Diesel engine Jack leveling 4 pin type jack Water tank capacity 130 liters Water pump Pulley driven self priming water pump Water discharge system Solenoid valve operated auto water feeding system ( at each batch operator needs to press push button to discharge) Weighing system Digital Load cell based weighing Hydraulic system for hopper Hydraulic cylinder operated Gear ring and roller Accurately machined gear ring and rollers for the better durability Hydraulic system for mixer Hyd. Motor Tyres 4 no of pneumatic tyres make Mixing and discharge of concrete Forward rotation of mixer mixes and reverse rotation for the discharge of concrete Three bin system Yes Mixing drum rpm 16 -18 rpm Towing speed and system 22 km /per hour Battery Exide make standard battery Control panel Microprocessor based control panel (scada system control panel ) extra ret in your location Tool box Yes Diesel engine 10 hp standard diesel engine with self start system and alternator ( HTC ENGINE/kirloskar engine )
Delivery Time12day
