Rolling Shutter Door Forming Machine

Sanxing is a world-class manufacturer, supplier, and exporter of Rolling Shutter Door Forming Machine. This line of produce uses galvanized sheets of steel and colored armor plate as the material plate. The machine comprises of a hydraulic uncoiler, a roll forming machine, heating device, forming machine, runout table and a pneumatic fly-saw cutter. Our product is used in shops, warehouses, working departments and fire partition.
Benefits :

• Non-fading bright color
• Rust resistant
• Three times higher than aluminum alloy door

Components of the Production Line :

• Hydraulic Uncoiler;
• Roll Forming Machine;
• Heating Device;
• Foaming Machine;
• Runout Table;
• Pneumatic Fly-saw Cutting;


Sketch processing flow :  Manual de-coiler--- Forming machine ----Hydraulic cutting--- Control system

Technical Specification :

• Material thickness : 0.5 - 1 mm
• Forming steps : 13 groups
• Forming speed : 10-15m/min
• Shaft material : #45 steel
• Shaft diameter : ¢ 48
• Roller material : #45steel, chromed
• Forming power : 3.0KW
• Cutting power : 1.5KW
• Cutter type : Hydraulic flying saw
• Control system : PLC (Omron brand)
• Overall size of machine(L x W x H) : 6 x 0.8 x 1 M
• Total weight : 2T
