Roof Tile Roll Forming Machine

We are offering Roof Tile Roll Forming Machine.
equipment Structure
forming Machine is Composed of De-coiler, Drive Device, Forming Roller, Main Forming Machine, Cutting Device, Hydraulic Pressure System, Electric Control System
main Technical Parameter
1，type of Finished Product(mm): About Width600-1100x Thickness(0.5-1)x Length
2，production Speed: 8～12m/min
3，quantity of Roller: 16-26 Sets
4， Main Reducer Power:5.5-7.5kw
5， Hydraulic Station Press: 10～12 Mpa
6，electric Control System: Plc Frequency Conversion Controller
7，dimension of Main Machine Frame: 8500mm×1700mm×1300mm.
