Roofing Tile Roll Forming Machine

Roofing tile roll forming machine
characteristic
this roll forming machine can roll form metal roofing step tile. After roll formed by this roll forming machine, the surface will be very smooth and beautiful without any scratch on surface.
roll forming process:
fully automatic control system with plc. easy operation: key in the length and quantity on the control panel. one year warranty. we also can do a custom roll forming machine, i.e. We can design the machine according to your specification and profile drawing.
one roll forming machine can produce one or two profile.
the following profile drawing are some examples for your reference.

composition of machine line
single head uncoiler
roll forming main machine
hydraulic cutting system
hydraulic station
control panel with fully automatic control system with plc
receiving table
specification
sheet thickness 0.3 ~ 0.8mm
forming speed 8~ 12m per minute
roller shaft dias φ75 mm
roller stations 12 ~ 16
length x width l 86~ 12 m w 750~ 1010 m
