Rotary Ice Cream Tub Filling Machine

Get Latest Price

Packaging TypeCardboard Box
ApplicationFilling Ice-cream Into Tubs
FeatureDispensing Of Tubs, Dry Nut Sprinkling (optional), Plastic Lid Dispenser, Ejecting Of Finished Tubs
Number Of FlowerIce Cream Filling Machine
Supply TypeManufacturer, Exporter, Supplier, Retailer
Preferred Buyer Location All over the world

View More Details

Send Enquiry

Company Information

Shreya Engineering Works

Vitthal Udyognagar, Anand, Gujarat

1.0/5

(1)

View Number

Member Since 22 Years
Nature of Business Retailer

Ask for more detail from the seller

Contact Supplier

Report incorrect details

View Company Details

Product Details
Company Details

Packaging TypeCardboard Box
Number Of FlowerIce Cream Filling Machine
FeatureDispensing Of Tubs, Dry Nut Sprinkling (optional), Plastic Lid Dispenser, Ejecting Of Finished Tubs
ApplicationFilling Ice-cream Into Tubs
Advantages Of PLCOnline Volume Setting, Automatic Shift Register Function (No Tub No Lid)
Varieties FilledDifferent Varieties Of Ice Creams
OperationFully Automatic

The Rotary Ice Cream Tub Filling Machine can fill different varieties of ice creams. The Rotary Ice Cream Tub Filling Machine use fully automatic operations such as Dispensing of tubs, dry nut sprinkling optional, plastic lid dispenser, ejecting of finished tubs and Filling of ice-cream into tub.

Advantage of PLC :

We set online volume IE Chocolate topping will equal for any speed either very low or very high speed
Important feature of plc is that automatic shift register function IE No tub no lid, hence we can save raw material & compressed air too

Specifications

Filling Quantity	Up to 1000 ml as required
Tub Despending	Automatic
Lid	Automatic
Ejecting	Automatic
Drive	0. 5 HP motor , vfd, ratchet indexing.
Machine Output	1200 tubs per hrs.
Air Supply	Maximum 6CFM, at 80 PSI
Electricity Supply	Cycle 50 htz. , 440 volts . 3 phase
Note : All the pneumatic components are festo make only Compressor is not in scope of our supply, provide by client The design & specifications of the machine illustrated herein are subject to change without notice. Other Information : Pay Mode Terms : L/C (Letter of Credit), Western Union, Other
