Rotary Joint, Brand Name : YJ, Model Number : MXQ2

We are offering rotary joint/ union -mxq2(steam).
mxq2 series adopts double-spherical sealing and double-pole external supporting structure. When the exterior provides enough space, minxuan double-pole supporting-type rotary joint can display its advantages of long service life and stable operation under high-speed and high conditions. The products are extensively applied in textile, paper making and packaging industries.
1、 the shell is cast overall with attractive appearance and compact structure.
2、 the rotation axis is formed by integrated bar stock heat stress and processing and spherical surface technological conformity of large batch of products. Meanwhile, the rotary axis is processed with special treatment to improve the hardness and corrosion resistance
3、 it is fixed and supported by external double-pole. It can display its advantages of long service life and stable operation under high-speed and high pressure conditions.
4、 the double spherical sealing structure enables to regulate the core and compensate automatically, which offsets the deflection and vibration of the rotator.
5、 the spring is made of heat-resistant stainless steel. Even under high temperature, it guarantees a good pursuit performance and compensation. Therefore, the sealing performance is better and the service life is longer.
6、 it is applicable to high-speed and high-pressure steam medium, featuring superior performance, long service life, reliability and fewer shutdown times.
operating parameter:
medium:steam, condensed water
temperature:≤350℃
rotating speed:≤300rpm
pressure:≤2.5mpa
