Rotary Screw Compressor

Supply TypeSupplier, Retailer
Preferred Buyer Location All over the world

Our company offers Rotary Screw Compressors with a fixed speed range of 15-22 kW. The different models offered are: L15 - L22. Some characteristics of these rotary screw compressors are listed....

View More Details

Send Enquiry

Product Details

Our company offers Rotary Screw Compressors with a fixed speed range of 15-22 kW. The different models offered are: L15 - L22.

Some characteristics of these rotary screw compressors are listed below:

Fully integrated air-end : The design of the high efficiency air-end operates at low rotational speeds, and as a result uses low amount of energy. This innovative integrated design, with oil separation, oil filter, thermostatic bypass valve, reduces the number of external hoses and components and hence results in increased reliability.

High efficiency drive : The L series range of our fixed speed compressors are fitted with a high efficiency IP55 IE2 motor to ensure operational reliability.

Small footprint : Designed to pass through a standard doorway ensures hassle-free installation.

Low noise levels : Reduced installation cost can be achieved by locating the compressor near to personnel or equipment without health and safety issues.

Delcos Pro Controller : The innovative controller provides dual position for simplicity of operation and cuts down the voltage requirement ensuring safe operation (24 V)

High quality air : This is achieved by the use of high efficiency air/oil separation system and optimum after cooling.

Up To 46 °C Ambient : This ensures continuous and stress-free operation through efficient heat dissipation.

High Quality Rotary Screw : Our range of oil-injected rotary screw compressors incorporate the very latest technology and manufacturing processes to provide users with a continuous supply of economic and reliable high quality compressed air.

Our company supplies a wide range of industrial equipment, out of our offices established in Delhi

Technical Specifications

L15-L22 Screw Compressor

Model	Motor Rating (kW)	Free Air Delivered m3/min1)			Dimensions (L x W x H) (mm)	Noise Level db (A)2)	Weight (kg)
Model	Motor Rating (kW)	7.5 bar g	10 bar g	13 bar g	Dimensions (L x W x H) (mm)	Noise Level db (A)2)	Weight (kg)
L15	15	2.70	2.26	1.80	787 x 698 x 1202	70	335
L18	18.5	3.25	2.74	2.34	787 x 698 x 1202	71	361
L22	22	3.65	3.21	2.61	787 x 698 x 1202	71	367

1) Data measured and stated in accordance with ISO 1217: 2009 Annex C and Pneurop / Cagi PN2CPTC2 and the following conditions:
Air Intake Pressure 1 bar a
Air Intake Temperature 20Ë� C
Humidity 0 % (dry).
2) Measured in free field conditions in accordance with ISO 2151 and ISO 9614-2, tolerance ± 3 dB(A).

CompAir policy is one of continuous improvement and we therefore reserve the right to alter specifications and prices without prior notice. All products are sold subject to the
Company’s conditions of sale.

Download Detail File : Click Here
