Contact SupplierStirring quantity max. (H2O) 80 l
Motor rating input 220 W
Motor rating output 90 W
Speed display scale
Speed range 60 - 1400 rpm
Viscosity max. 50000 mPas
Output max. at stirring shaft 90 W
Permissible ON time 100 %
Torque max. at stirring shaft 900 Ncm
Torque max. at stirring shaft at 60 1min (overload) 1144 Ncm
Torque max. at stirring shaft at 100 1min 900 Ncm
Torque max. at stirring shaft at 1.000 1min 86 Ncm
Speed range I (50 Hz) 60 - 400 rpm
Speed range II (50 Hz) 240 - 1400 rpm
Speed range I (60 Hz) 72 - 480 rpm
Speed range II (60 Hz) 288 - 1680 rpm
Speed control stepless
Stirring element fastening chuck
Chuck range min. diameter 1 mm
Chuck range max. diameter 10 mm
Hollow shaft, inner diameter 10.5 mm
Hollow shaft (push-through ¿ when stopped) yes
Fastening on stand extension arm
Extension arm diameter 16 mm
Extension arm length 145 mm
Torque display no
Nominal torque 9.0 Nm
Dimensions (W x H x D) 123 x 364 x 252 mm
Weight 7.4 kg
Permissible ambient temperature 5 - 40 °C
Permissible relative moisture 80 %
Protection class according to DIN EN 60529 IP 42
RS 232 interface no
Analog output no
Voltage 220 - 240 V
Frequency 5060 Hz
Power input 220 W
