Samway P18LED Hydraulic Hose Crimping Machine

Samway P18LED Hydraulic Hose Crimping Machine
Feature description
Elbow 90 dgree hose up to 1"
Portable 1" 4SP Crimper
� No electricity required
Optional Enerpac Pneumatic Pump
Complete Die Set
With LED indicator
Specification
Main Specification
SAMWAY P18LED
Max Hydraulic Hose
1" 4SP
Crimping Range mm
4-60
Die Type
P18
Master Die Length mm
64
Max Opening mm
+20
Optional hand Pump
Enerpac two stage pump 700 bar
Crimping Force KN
1200
Control
Micro Dail
L*W*H mm
190*180*310
Weight KG
22
Standard Die Sets Included�
Die No. 10 12 14 16 19 23 27 31 37
Length 55 55 55 55 55 55 65 65 65
