SAW Pipe X Ray Inspection Radiography Machine

225KV SAW pipe  X Ray inspection radiography Machine As a technical achievement which researched by Dandong NDT equipment Co., Ltd for many years, CMH series industrial X-ray pipe inspection radiography system is a complete set of automatic glide inspection equipment which manufactures according to user`s requirements.it is the first set of leading products which can finish pipe inspection under φ219mm diameter, with many years searching and learning, we have made biggest SAW pipe inspection line in domestic, the pipe diameter can up to 3500mm. CMH series industrial X-ray hub inspection radiography system got honors as [hi-tech technical product" and so on. Until now it gets more than 100 sets achievement. This series of X Ray Pipe Detector is new kind of RTR inspection system which is professionally manufactured for SAW inspection, it can divide into end load material and trolley load material two series of products, we can design and manufacture according to different requirements, it can satisfy the inspection requirements of both straight welding and circular welding. This system mainly consists of seven parts as X-ray machine, image intensifier, image process system, monitor unit, Mechanical system, electrical controlling system and protective alarming units, covers electric, unit, light three technical areas, with cooperation between X-ray and industrial TV, users can view real time inspection images directly.
