Screw Making Machines, Power : 450W

Application Scope:
The series is suitable for screen printing screen high-precision photographic emulsion coating.
Features:
(1) PLC programmable controller and HMI composition as the operating control system.
(2) Full automatic operation via touch-screen settings, ordinary plate-maker can be easy to produce high-quality precision screen.
(3) Fixing clamps Unlock clamps set by a foot switch which controls the air pressure, easy to load and unload screen.
(4) Coating speed, coating time and a single, double-sided coating can be freely set.
(5) With pressure regulating function, the coating thickness can be controlled via a set number of application times and applying pressure.
(6) While reaching stop position would automatically slow down to 20mm near the frame, no need to fix screen extra edges.
(7) Use of rail steel with special low vibration, ripple-free coating process.
(8) Operating system with multi languages, multiple coating patterns, and detailed parameter settings.
(9) Special corrosion-resistant treatment aluminum scoop coater, with no clearance with the coating structure, maintain stable emulsion coating.
(10) Servo motor driven is optional.
Parameters:
Model
CAD-1000
CAD-1315
Max frame size (OD)
1000 X 1000mm
1300 X 1500mm
Min frame size (OD)
600 X 600mm
600 X 600mm
Coating speed
50 ~ 150mmsec
Frame fixing
Foot switch quick fixed
Air pressure
6kgcm2
Weight
Approx. 380kg
Approx. 450kg
Power
220V X 1ph X 450W
220V X 1ph X 600W
Dimension (W X D X H)
1920 X 580 X 1900mm
2120 X 580 X 2300mm
★ Customized frame size can be made for requirement.
