Sdi To HDMI Multifunctional Converter

We offer sdi to hdmi multifunctional converter.
Kv-cv180a sdi to hdmi&av(cvbs) multifunctional converter is a professional converter which can be convert the (sdi,hd-sdi and 3g-sdi) to hdmi and av analog signal. The kv-cv180a be integrated sdiã��ã�â¢ã�â¯ã�â¿ã�â½ã�â¯ã�â¿ã�â½s transmitter and hdmiã��ã�â¢ã�â¯ã�â¿ã�â½ã�â¯ã�â¿ã�â½s receiver, sdi can be easily convert to hdmi, separate and convert the audio of sdi then embed to hdmi to achieve audio and video transmit simultaneously.
Sd to hdmiav(cvbs) multifunctional converter
kv-cv180a sdi to hdmiav(cvbs) broadcast grade multifunctional converter can convert sdi to hdmiav(cvbs)
input interface: 1x bnc sdi output interface: 1x bnc sdi1ã��ã¯â¿â½ã�â¯ã�â¿ã�â½hdmi1ã��ã¯â¿â½ã�â¯ã�â¿ã�â½av
features:
support sdi input format( all and any sdi format)
sd: 525i @ 59.94hz, 625i @ 50hz
hd: 720p @ 23.98hz 24hz 25hz 29.97hz 30hz
720p @ 50hz 59.94hz 60hz
1080i @ 50hz 59. 94hz 60hz
1080p @ 23.98hz 24hz 25hz 29.97hz 30hz
3g: 1080p @ 50hz 59.94hz 60hz
support smpte 425m(a and b level)ã��ã�â¯ã��ã�â¼ã�â¯ã�â¿ã�â½smpte424m
with 1 channel sdi loopback output
support osd and menu operation page
detect hdmi edid information & adapt to best hdmi mode automatically
support all format dissymmetric conversion
blue screen warning when signal loss
automatically embed sdi audio signal to hdmi signal.
