Seam Welder, Brand Name : SBKJ

We are offering seam welder.
features :
1. Cross sea longitudinal seam and horizontal and vertical seam.
2. The speed of welding is quick and the efficiency of welding is high.
3. According to the clients’ demand, set the function of continuous weld and pulse weld.
4. Equipped with a high reliability control box
5. The welding speed can be regulated continuously.
6. Suitable for the site for welding airproof vessel
type:sbfn-35~sbfn-100
thickness:0.4-1.0mm,0.4-2.0mm
max input capacity:45kva,110kva
max short circuit current:6200a,26000a
max pressure of electrode:400kgf,1000kgf
the flow of cooling water:6lmin,8lmin
arm length:600mm
electrode journey:80mm
speed of welding:0.5-3mmin
weight:328kg,478kg
dimension:1800*610*1930mm.
