Self-Adjust Welding Rotator Roller, Brand Name : YAOQIANG

Self-adjust welding rotator roller
1.equipment structure types:fixed or mobile(optional);
2.driving mode:single,double speed reducer drive motor
3.roller quantity:8set
4.rolled steel:steel&rubber rollercombined.
5.mode:ac frequency conversion stepless speed
6.support workpiece:clamp ampere frame automatically open&automatic reset
7.electrical system:the remote control cabinet+box(line 10-15m)or pedal switches.
Model max. Load kg allowed work piece wheel diameter and width wheel linear speed motor power speed adjustment method
(mm) (mm) (mh) (kw)
rubber metal
single drive(kw) dual-drive(kw)
hgz5 5000 φ250-2300 φ250×100 2×φ244×20 6-60 0.75 ac frequency converter stepless speed adjust.
Hgz10 10000 φ320-2800 φ300×120 2×φ294×25 6-60 1.1
hgz20 20000 φ500-3500 φ350×120 2×φ344×30 6-60 1.5
hgz30 30000 φ500-4000 φ350×120 2×φ344×30 6-60 2.2
hgz40 40000 φ600-4200 φ400×120 2×φ394×40 6-60 3 2*1.5
hgz50 5000 φ600-4500 φ400×120 2×φ394×40 6-60 3 2*1.5
hgz60 60000 φ750-4800 φ450×120 2×φ444×50 6-60 4 2*2.2
hgz80 80000 φ850-5000 φ500×120 2×φ494×60 6-60 4 2*3
hgz100 100000 φ1000-5500 φ500×120 2×φ494×80 6-60 5.5 2*3
hgz150 150000 φ1100-6000 φ600×280 6-60 7.5 2*4
hgz250 250000 φ1200-7000 φ700×300 6-60 11 2*5.5
