| Model | Item | Units | Specifications |
| Comtainer | Product material | / | PET |
| Volume | L | 0.1-2 | |
| Theoretical output | PCS/H | 1200-1600 | |
| Preform length | Mm | 15-350 | |
| Preform inner diameter | Mm | φ5-38 | |
| Mould | Max.mould plate Dismeter(L×W) | Mm | 350 * 380 |
| Max.mould thickness | Mm | 180 | |
| Clamping force | KN | 45 | |
| Mould opening stroke | Mm | 16 | |
| Machine size and weight | Main machine(L×W×H) | Cm | 160 * 60 * 161 |
| Main machine weight | KG | 500 | |
| Heater(L×W×H) | Cm | 187 * 63 * 145 | |
| Heater weight | KG | 250 |
