Semi Automatic Grid Casting Machine

This machine is best suited for small scale & medium scale battery plate & battery manufacturers or for longer Industrial negative grid where the grid mould are heavy & manual casting are not possible. It is a simple equipment which consists of a main frame on which the grid mould mounting block with grid mould opening / closing & grid ejection mechanism is mounted. Various grid type moulds could be mounted on this. Grid mould opening & closing is continuous & the timing could be set. When the mould opens, the grid is ejected automatically. Trimming is not necessary since dropping legs are not provided & the gate portion is made for manual cutting.

Lead pouring could be manual or by a pneumatic operated laddle. Lead is generally poured either directly into the mould or into the laddle from the furnace. Grid moulds are provided with water cooling lines & cartridge heater brackets. Temperature of grid mould is controlled by Automatic Digital Controller.
