Semi Automatic Magnetic Strip

We are offering semi automatic magnetic strip.
Equipment function and application introduction
the machine controlled by relay, use imported temperature control implement to control the temperature, the spot welding time is controlled by time relay, the magnetic tape can be mounted on the covered film under the heating and pressure. It is available for mounting sheet material.
feature :
use double cylinders to be motivity, the pressure of the welding spot can be adjusted, the magnetic strip
welding spot is level off and firm.heating temperature control method: use the heater to heat up and the import thermocouple cooperating with temperature controller to control the temperature, it is easy to set
and the temperature controller is precision. The spot welding time controlled by time relay and the time can be adjusted as needed. It is simple and convenient for setting.
technical parameters:
power source ac 380v50 hz available material 0.25~0.8mm covered film sheet
air source 6 kgcm2(no water) tape type accord with isoiec7811
high density and lower
density magnetic strip
total power 3kw tape width 12.7mm 6.35mm plate dia.380mm
temperature control range 0-400℃
(can be set) tape amount 5~8 pcs
temperature control precision ±2℃ available sheet 3×8、4×8、5×5(with choice)
laying precision ±0.2mm operator 1 person
weight approx.200kg overall dimension l800×w700×h1500mm
output 230~400sheetsh
