Semi Automatic Screw Capping Machine

Supply TypeManufacturer, Exporter, Supplier, Retailer
Preferred Buyer Location All over the world

The semi automatic cap sealing machine is precision built on sturdy welded steel frame completely enclose in stainless steel sheet and doors are provided to facilitate the servicing of machine.....

View More Details

Send Enquiry

Company Information

Medi Pack Process Technologies

Sardar Patel Ring Road, Ahmedabad, Gujarat

View Number

Member Since 12 Years
Nature of Business Retailer

Ask for more detail from the seller

Contact Supplier

Report incorrect details

View Company Details

Product Details
Company Details

The semi automatic cap sealing machine is precision built on sturdy welded steel frame completely enclose in stainless steel sheet and doors are provided to facilitate the servicing of machine. Machine is having motorized rotating head mechanism, which ensures proper cap sealing with uniform torque.

Operation :

Require manually feeding & unloading container, where the body and the neck of the container are positioned below the rotating head, and sealing head is performing perfect operation of capping with uniform torque.

Salient Features :

The unit is made compact & versatile.
S.S. Elegantly Matt Finished Body.
Built in front control panel.
Quick setting.
Motorized head movement.
No change parts require for different container diameter.
Low noise level, low power consumptions.
Adjustable bottle height gauge for easy and quick setting.
SS cladding or hard chrome platting of all exposed parts to ensure long life and resistance against corrosion.
Sealing pressure can be varied to suit different gauges and size of caps.

Technical Specifications :

Model

Output/Hour*

No. of sealing head

Electrical Motor**

Overall Dimension

Case Dimension

Net Weight

Gross Weight

Change parts required

Input Specifications

Screw Cap Specification

Diameter**	18 mm to 56 mm***
Height**	15 to 20 mm

Container Size**

Round Shape	Ø 22 mm to Ø 100 mm* Respectively height 58 mm to 240 mm* (Height option for other bottle height available)
Flat / Square	15mm to 100 mm (Length) Respectively 10mm to 50 mm (Width) Respectively height 58 mm X 240 mm (Height option for other bottle height available)

* Depends on bottle size, cap size and type of cap.
** We can supply as per customer requirements.
*** With help of change parts.
