| Model | GCGHY - 200 - AF | GCGHY - 200 | GCGH - 200 | GCGC – 25 |
|---|---|---|---|---|
| Operating System | Auto Feeding | Semi Automatic | Manual | Manual |
| Production Per Hour | 325 - 350 Arbour | 275 - 300 Arbour | 225 - 250 Arbour | - |
| Centreless Attachment For R/F & S/F |
Pneumatically Adjustable Grinding Time |
Hydraulically Adjustable Pressure & Grinding Time |
Manual | - |
| Longer Roller Link Comber / Draw Frame etc. |
Grinding Between Centres, Taper Grinding System Provided form Comber Detaching Roller | |||
| Grinding Accuracy & Surface Finish |
± 0.01 Ra Value < 0.5 umm | |||
| Lubrication System | Centralise System By Manual Pump | |||
| Connected Electric Load | 3.3 KW (4.5 HP) 3 Phase | |||
| Dust Extraction | Provided Separately | |||
| Compressed Air Pressure | 6- 10 Bar | |||
| Grinding Wheel Dimensions | Ring & Speed Frame - 250 O/D X 150 I/D X 200 Wude Longer Roller - 250 O/D X 150 I/D X 25 Wide |
250 P/D X 150 O/D X 25 Wide | ||
| Working Range Min. Dia Max. Dia Max. Length |
Ring & Speed Frame Draw Frame/ Comber Roller 26 MM 20 MM 38 MM 100 MM 190 MM 500 MM |
|||
| Weight Net/ Gross Kgs | 1200/1600 | 1100/1500 | 1100/1500 | 950 /1350 |
| Size of Case Machine Dust Extraction |
160L X 130W X 160H cms 110L X 81W x 15H cms |
|||
