TVS KING THREE WHEELER

Number Of Flower4 stroke single cylinder, forced air cooled, spark ignition (SI) Engine
Supply TypeManufacturer, Exporter, Supplier, Retailer
Preferred Buyer Location All over the world

Company Information

Ask for more detail from the seller

Report incorrect details

Number Of Flower4 stroke single cylinder, forced air cooled, spark ignition (SI) Engine
Front & RearTrailing arm type, constant rate coil spring with co-axial hydraulic damper
Fuel feed systemSide draft carburetor-intake and exhaust controlled by valve mechanism
Wheels & Tyres
Front & RearDrum, Hydraulic
StartingElectric & Hand Start
Transmission4 forward and 1 reverse speed, constant mesh, fork & cam type shift mechanism
Rim size- Front & rearDrum, Hydraulic
Chassis
LubricationPositive displacement type oil pump mounted on an oil stump
Maximum torque12.9 + 0.6 Nm 3250 + 300 rpm
Suspension
Maximum power5.5 + 0.3 kw / (7.37 bhp) 5000 + 300 rpm
Brakes
Tyre size- Front & rear4.00-8,6 PR
Compression ratio9.6 + 0.3:1
Displacement199.26 cc
Bore X Stroke62 mm X 66 mm
Transmission
IgnitionHigh Energy Inductive Ignition
