Nitrile Rubber Sewage Suction Discharge Hose, Color : Black

₹ 1,820 - ₹ 27,300 / meter

MaterialNitrile Rubber,Rubber
Brand NameBiaohui
Size (Inches)50-500mm
ShapeRound
Supply TypeManufacturer
Preferred Buyer Location China only

Product Details

Country of OriginChina
UsageIt Can Be Used To Deliver Sand,Slurry And Gravel. It Is Resistant To Corrosion,So It Is Also Used
Pressure16bar
ColorBlack
ShapeRound
MaterialNitrile Rubber,Rubber
Brand NameBiaohui
Size (Inches)50-500mm

Sewage Suction and Discharge Hose is resistant to abrasion, so it can be used to deliver sand, slurry and gravel. It is resistant to corrosion, so it is also used to deliver corrosive sewage, and this is sewage suction & discharge hose. It has excellent flexibility and it can be connected tightly to pipeline. Its structure is similar to Sewage Suction and Discharge Hose and seawater suction & discharge hose. It is composed of three parts: tube, reinforcement and cover. Tube is made from high quality synthetic rubber (NR, SBR and BR), making hose resistant to corrosion and work well in delivering sewage. Reinforcement is made from multiple layers of high tensile spiral steel wires, making hose resistant to bending and fatigue. And sewage suction & discharge hose can bear very high working pressure due to the high tensile spiral steel wire reinforcement. Cover is made from NR, SBR or BR, making hose resistant to corrosion, abrasion, weather, ozone and aging.

The details of sewage suction & discharge hose:

Structure: composed of three parts: tube, reinforcement and cover.
- Tube: synthetic rubber, NR, SBR or BR, making hose resistant to abrasion, corrosion and seawater.
- Reinforcement: multiple layers of high tensile spiral steel wires, making hose have solid structure and resistant to kink and high pressure.
- Cover: synthetic rubber, NR, SBR or BR, making hose resistant to abrasion, corrosion, seawater, heat, weather, ozone and aging.
Working temperature: 20 °C to 80 °C.

The specification of sewage suction & discharge hoseHose codeIDODWorking pressureBurst pressureVacuum pressureLengthinchmminchmmbarMPabarMPabarMPamSWSDH-01SWSDH-02SWSDH-03SWSDH-04SWSDH-05SWSDH-06SWSDH-07SWSDH-08SWSDH-09SWSDH-10SWSDH-11SWSDH-12SWSDH-13

6	152	7-1/4	184	12	1.2	24	2.4	0.8	80	20
8	203	9-1/5	233	24	2.4	24	2.4	0.8	80	20
10	254	11-1/5	284	10	1	20	2	0.8	80	10
12	304	13-2/5	340	10	1	20	2	0.8	80	6 - 10
14	355	15-2/5	390	10	1	20	2	0.8	80	6 - 10
18	457	19-1/5	487	7	0.7	15	1.5	0.8	80	6 - 10
22	560	23-3/5	600	7	0.7	15	1.5	0.8	80	6 - 10
24	635	25-3/5	650	7	0.7	15	1.5	0.8	80	6 - 10
28	711	29-3/5	752	7	0.7	15	1.5	0.8	80	6 - 10
32	813	33-1/2	850	5	0.5	10	1	0.8	80	6 - 10
40	1016	41-1/2	1054	5	0.5	10	1	0.8	80	6
48	1219	49-1/5	1250	5	0.5	10	1	0.8	80	6
52	1320	53-1/5	1350	5	0.5	10	1	0.8	80	6
We can manufacture sewage suction & discharge hose according to customers' requirements, such as material, length, inner diameter, outside diameter.
