Contact Supplier| Power Range | 0.5, 1.0 & 1.1 HP |
| Version | 220-240V, 50 Hz, A.C.-1 Phase,. Permanent Split capacitor (PSC) Incorporated with Thermal Overload Protector. |
| Speed | 2880 rpm. |
| Duty | S1 (Continuous) |
| Degree of Protection | IP 54 |
| Insulation | Class B |
| Discharge range | 960 - 3080 Iph |
| Head range | 12 - 28 mtr. |
| Suction lift up to | 8 mtr. |
| Suction x Delivery size | 25 x 25 mm |
| Material of Construction | |
| Pump Casing | Cast Iron / MS |
| Motor Body | Aluminum / Cast Iron |
| Impeller | Cast Iron / Noryl |
| Diffuser | Cast Iron / Noryl |
| Shaft | EN-8 |
| Sealing | Mechanical Seal (Carbon V/s Ceramic) |
