Contact SupplierTrailer weight (Unladen) | 6.4 T ( APPROX ) |
Chassis |
All steel welded construction. 2 Nos. Main longitudinal members are high strength lighter weight Parallel flange Beam of ST 52 (or) Equivalent grade steel running along full length of the trailer. Cross members - Rolled or Folded of material IS-2062/ST-52 are positioned at suitable locations. 3.15 MS chequered sheet platform. Fixed front and side panel, drop down rear door shall be provided. 1 window shall be provided at middle on both sides. |
Landing leg | Two speed landing leg shall be provided at the front end. |
Axles | 3 Nos. 13T Axle Shall be provided |
King pin | 2” king pin equivalent to IS : 6763 Part I provided |
Suspension | 12T capacity Tandem axle leaf spring suspension with load equalizing brackets. |
Tyre Wheel rim | 10.00 x 20 – 16 PR – 12 Nos. 7.50 x 20 – 12 Nos. |
Brakes | Twin line air brake system coupled to tractor brake system. Trailer brakes are actuated from tractor. T24 brake chamber shall be provided on all axles. Limiting & Quick Release Valve shall be provided for brake efficiency. Parking brake shall be manually actuated. |
Electrical | 24V DC electrical include tail lamp, brake lamp and direction indicator lamps fitted at rear end of trailer. Side Marker lamps shall be provided on both sides. |
Surface preparation | Trailer surface shall be Shot blasted and cleaned. |
Painting | Two coats of mono coat finish paint with colour of customer choice. |
Other fitments | Fitments such SUPD, RUPD, reflectors on both sides and rear shall be provided as per CMVR |
