Single Column Vertical Lathe

Supply TypeManufacturer, Exporter, Supplier, Retailer
Preferred Buyer Location All over the world

Product Introduction Main features: Rough and finish machine Hydro-static guideway, head load capacity High precision, low noise High wear-resistance DRO available as optional

View More Details

Send Enquiry

Company Information

well win machinery

Kathwada, Ahmedabad, Gujarat

View Number

Member Since 7 Years
Nature of Business Retailer

Ask for more detail from the seller

Contact Supplier

Report incorrect details

View Company Details

Product Details
Company Details

Items	Unit	C5110	CD5112	CD5116	C5120
Max. Cutting dia. for vertical toolpost	mm	1000	1250	1600	2000
Max. cutting dia. for sideway toolpost	mm	1000	1100	1400	1800
Table dia.	mm	900	1000	1400	1800
Max. work height	mm	800	1000	1000	1250
Max. work load	T	2	3.2	5	8
Table speed range/16 steps	rpm	8-250	6.3-2000	5-160	4-125
Feed range for both toolposts		0.9-103	0.8-86	0.8-86	0.8-86
Horizontal travel for vertical toolpost	mm	670	700	900	1110
Vertical travel for vertical toolpost	mm	650	650	800	800
Horizontal travel for sideway toolpost	mm	500	500	650	630
Vertical travel for sideway toolpost	mm	810	900	900	1110
Ram travel	mm	580	650	650	890
Main motor power	kW	22	22	30	30
Overall dimensions	mm	2107x2711x3515	2375x2280x2938	2645x2630x3048	3210x2850x3910
Machine weight	T	7.1	8.5	13	17.5
