Single Side Adjustable Z Purlin Roll Forming Machine

Single Side Adjustable Z Purlin Roll Forming Machine
A). Main Components:
Decoiler -------------------------------------------- 1 Unit
Feeding & Leveling -------------------------------- 1 Unit
Hydraulic punching device ------------------------ 1 Unit
Main roll forming machine ------------------------ 1 Unit
Hydraulic cutting device --------------------------- 1 Unit
Hydraulic Station ----------------------------------- 1 Unit
PLC computer control ------------------------------ 1 Unit
Output table ---------------------------------------- 1 Unit
B). Work Flowing:
Decoiler --- Fedding & Leveling --- Punching --- Roll Forming --- Cut-to-length --- Run out table
C). Main Specification:
Material: GI, Carbon steel
Material thickness: 1.5-3.0mm
Machine diameter: about 11500x1500x1300mm ( LXWXH )
Weight of machine: about 11 Ton
Decoiler: Manual or hydraulic decoiler ( customer can choose )
Weight capacity of decoiler: 5 Ton
Principle axis:Principle axis
Forming speed: 0-15mmin
Drive type: 1.5' chain transmission
Roller material: GCr15 steel, quenched and heated process
Main power: 18.5KW
Hydraulic power: 11KW
Punching:hydraulic punching
Electrical Control: PLC Frequency Control System with touch screen
PLC: PANASONIC Brand
Encoder: OMRON Brand
Transducer: PANASONIC Brand
Applications:
Z purlin, z shaped purlin, z channel, z section, z profile, z shape, steel z purlin, z purlin steel structure
