Sinotruk Howo Concrete Mixer Truck 8cbm 6x4

MOQ1 Piece(s)
Brand NameSINOTRUK
CONCRETE MIXER TRUCKcement mixer truck
motomixerGood performance
Supply TypeManufacturer, Exporter
Preferred Buyer Location All over the world

We are offering sinotruk howo concrete mixer truck 8cbm 6x4. main description overall dimensions:8840mm*2495mm*3850mm(l*w*h) tare weight:11860kg payload:20000k front overhang:1500mm rear....

View More Details

Send Enquiry

Product Details

We are offering sinotruk howo concrete mixer truck 8cbm 6x4.
main description
overall dimensions:8840mm*2495mm*3850mm(l*w*h)
tare weight:11860kg
payload:20000k
front overhang:1500mm
rear overhang:2365mm
wheelbase3625mm+1350mm
track (fr):2022mm1830mm
chassis brand:sinotruk howo
chassis model:zz1257m3641w, driving type 6x4
cab:hw76, left hand drive, air-conditioner, one sleeper
engine:sinotruk wd615.87, 290hp, euro ii emission standard
transmission:hw15710, no. Of speeds: 10 forward & 2 reverse
steering:german zf8098, turning system pressure 18mpa
rear axle:hc16 tandem axle, rated load 2x16ton, ratio 5.73
wheels and tires
rim 8.5-20; tire 12.00r20, 10 units; spare wheel carrier: with one spare wheel
brakes
service brake: dual circuit pneumatic brake; parking brake: spring energy, compressed air operating on rear wheels; auxiliary brake: engine exhaust brake
mixing volume:8cbm
water tank volume:440l
hydraulic pump
brand: ark, italy
motor
brand: ark, italy
speed reducer
brand: topunion, italy
