Medcounty Electric Six Channel ECG Machine, Color : White

MEDCOUNTY Six Channel ECG Machine

MC-ECG6

Features

• 7" inches TFT, touch screen, led backlight

• Digital isolation technology and signal processing solution, digital filter

• Patient management, name, age and id.

Detail analysis report.

• Buit-in lithium rechargcable battery, wide thermal printing system.

• USB and LAN socket.

• Memory: Built-in memory or mini SD Memory card. Stores more than 1000 pieces of archive

• Auto-measurement, auto-analusis, and auto-interpretion.

Techincal Parameters

Lead

Standard 12 leads

• Patient leak current

=50M

• Frequency response

0.05 ~ 150HZ(-3dB)

• Time constant

>3.25

• CMRR

>100dB

• Dimension of recording paper

110mm x 20Mtr.

• Paper speed

25mm/s, 50mm/s

• Sensitivity choice

5, 10,20mm/mV.

• Measurement parameters

Duration,

HR, P-R interval, P-QRS Duration, Q-T interval, Q-Tc,P Axis, QRS Axis, T

Axis, R(V5), S(V1),

R(V5)+S(V1)

• Product safety type

Class I, CF. Defibrillation pacing protection

• Enduring polarization voltage

+ 300my

• Nosie level
