SJ-A55 PE Film Blowing Machine

SJ-A55 Single layer Film Blown Machine is used to make high density or low density polyethylene (HDPE or LDPE) into plastic film. It can produce packing film, laminating film, bags or film for textiles and clothing, agricultural covering film, and other packing material. The machine can can virgin material, also recycled material to produce film. The Film Blowing extruding machine includes following parts: screw and barrel, motor, inverter, die head, heaters,winder, and tower. The main motor have frequency control (inverter control) of motor speed to improve the speed regulation and save electricity of 30%. The screw & material barrel is made from a nitrogen-treated chromium-molybdenum-aluminum alloy, 38CrMoAl.  Technical variables: Model A50 A55 A65 A65-1 Diameter of screw Φ50 Φ55 Φ60 Φ65 Reduced diameter of film(mm) 100-600 200-800 300-1000 400-1200 Single-face thickness of film(mm) 0.01-0.10 0.01-0.10 0.01-0.10 0.01-0.10 Max. Extrusion(kgh) 35 50 65 80 LD 28:1 28:1 28:1 28:1 Power of main motor(kw) 7.5-11 11-15 18.5-22 22 Power of Traction motor(kw) 1.1 1.1 1.5 1.5 Heating Power(kw) 11 13 19 21 Outline diameter(L*W*H)(mm) 4800*1900*3500 5500*2100*3800 6500*2300*4200 6500*2500*6000 Weight(T) 1.5T 2T 2.3T 2.6T
