Small Hexagonal Wire Netting Machine

We are offering small hexagonal wire netting machine.
hexagonal wire mesh machine is our main product, the main type is 3/8,1/2, 5/8,.3/4, 1,1.2,1.5,2 inch and so on.we can also do as you required. The machine can produce the mesh wire and the max width are 1.2m and 2.3m. The machine with 2.3m mesh width can produce two 1m mesh at the same time. The wire diameter is usually range from 0.38mm to 1.3mm. It depend on the mesh size.
the main component is one main machine, one spring winding machine and one spool winding machine.
main machine
1.net width:1.2m/2.3m.
2.mesh size:1/2,3/4,5/8,1,1.5,2,2.5.
3.wire diameter: 0.38mm~1.5mm.
netting width1.2m:length2.65m, width1.9m, height1.3m, weight2t, power2.2kw.
netting width2.3m:length3.65m, width1.9m, height1.3m,weight2.5t,power2.2kw.
spring winding machine
overall dimension:2050mm*700mm*1500mm(length*width*height)
power:0.75kw
weight:100kg
spool winding machine
overall dimension:850mm*700mm*1000mm(length*width*height)
power:0.75kw
weight:50kg
can also do as the customer required!
