Soil Consolidation Apparatus

Description and Specification for Lab Tenders

Consolidation Apparatus (Three Gang Model).

The Flexure Strength Testing are designed to test flexural strength of concrete beams.

The design provide maximum rigidity throughout their working range. The load is applied by the downward movement of the piston. A spacer is for testing different size of beams. The load is indicated on a calibrated bourdon tube type load gauge of range: 0 - 100 kN x 0.5 kN (0- 1O,000 kgf x 50 kgf). The load gauge is calibrated against National Council for Cement and Building Materials Certified Proving Ring. Flexure Testing Machines1. Light weight, rugged high strength frame2. Double action hydraulic pump3. Self-aligning roller assembly4. Hydraulic jack provided with retraction spring5. For testing beams of 100 x 100 x 500mm and 150 x 150 x 700mm6. Conforms to IS 516, BS 1881 and ASTM C 78 Two Models are available but consists of 3 consolidation test assemblies mounted on a single frame. Complete with 3 sets of Consolidation cell assembly for 60mm dia samples and three sets of weights each giving 10 kg/sq.cm. On each sample. civil lab equipments manufacturers
